【MSDS01】Smart Door & Window Sensor – Wireless Magnetic Contact for Home Security
The Smart Door & Window Sensor detects the open and close status of doors and windows in real time.
Once triggered, it instantly sends notifications to the user’s smartphone via the Tuya Smart / Smart Life App, allowing users to stay informed anytime, anywhere.
With its compact design, low power consumption, and easy installation, it is ideal for smart homes, apartments, offices, hotels, and rental properties.
Key Features & Advantages:
- Real-Time Door & Window Status Detection
- Tuya Smart App Notification & Alert System
- Smart Scene Linkage with Other Tuya Devices
- Low Power Consumption & Long Battery Life
- Wireless Design with Easy Installation
- Compact & Minimalist Appearance
- Suitable for Home, Office, Hotel & Security Systems
Share:
Facebook
Twitter
LinkedIn
WhatsApp
Table of Contents
DESCRIPTION
Product Specifications
| Product name: | Wifi Smart Magnetic Door Sensor |
| Input voltage : | DC3V LRO3(2*AAA, not included) |
| Quiescent Current : | ≤45UA |
| Alarm Current : | ≤ 130mA |
| Low power undervoltage : | ≤2.4V |
| WiFi: | 2.4GHz 802.11b/g/n |
| Colors: | White |
| Magnetic control distance : | ≤15mm |
| Working temperature: | - 10~+50°C |
| Working humidity : | max 95 % RH |
| Function: | Intelligent linkage Low power consumption Low battery reminder Door open alert APP notificationHome burglar Zero false alarm |
| Product Size： | 70x25mm |
| Part Number: | 【MSDS01】 |
Product SKU List
| Picture | Network mode | Regular color |
|---|---|---|
 |
WiFi | white |
|
|
Zigbee | white |
Product Display
Product Description
Trading Information
| Packaging Details: | The inner packaging is packaged with a packaging box containing an inner support structure, which can effectively prevent the product from being damaged during transportation. The outer packaging adopts a compression-resistant structure, which can effectiv |
FAQ
Q1: Where is the product manufactured?
A1: The product is manufactured in China.
Q2: certifications does this product have?
A2: The product has CE/FCC/ROHS certifications.
